DESCRIPTION

Basic Info.

Model NO.	PG M MG
Usage	Used Formachinery Control Box etc.
Transport Package	Export Packing
Specification	PG07---PG63
Trademark	FATO or OEM
Origin	China
HS Code	3926909090
Production Capacity	500, 000PCS/Day

Product Description

Product Description:
1,PG CABLE GLANDSMaterial: made of UL Nylon 66,94-2 and tight ring from rubber.Feature: Special design,no need to dismantle the fix terminal,cable can be inserted though directly then tighten easy and save time.Application: used formachinery control box,distribution plate,machine and electrical,etc.

Ietm No.	D1	D2	L1	L2	L3	B1	Cable range
PG-7	10.9	8.1	10.4	14.5	10.5	6.4	3.5-6
PG-9	15.3	12.2	9.9	15.8	17.2	8.6	4-8
PG-11	17.9	14.6	10.6	15.5	17.2	8.6	4-8
PG-13.5	20.2	16.2	10.3	17.8	17.9	13.3	6-12
PG-16	21.3	18.3	11.2	18.5	20.5	14.3	10-14
PG-19	24.7	20.5	11.4	18.6	21.8	15.5	12-15
PG-21	26.9	21.8	11.6	18.7	23.1	16.7	13-18
PG-25	29.8	25	12.1	28.3	24.1	19.2	15.22
PG-29	35.1	29.8	12.4	22.6	24.8	24.8	18-25
PG-36	44.7	37.1	12.6	25.1	26.1	30.7	22-32
PG-42	50.4	43.3	17.3	25.9	30.5	35.6	30-38
PG-48	56.1	48.2	20.9	28.1	31.5	41.4	34-44
PG-63	71	63.5	27.5	31.5	43.5	55	42-54

2,MG CABLE GLANDSThreade entry:MetricColor:Black and greyOperating Temperature:-40ºC--100ºC,and can also endure 120ºC instantly.Protection: IP68

Ietm No.		Threaded entry metric	Cable rangeø	Thread O.D C1	Panel moting Hole	Thread length C2	Sealing nut size F	Lock nut size A
Black	Grey
MG12-08B	MG12-08G	M12×1.25	7.6-4.6	12	12.5	8.5	19	18
MG16-10B	MG16-10G	M16×1.5	10-6	16	16.5	15	22	22
MG20-14B	MG20-14G	M20×1.5	14-9	20	20.5	15	27	27
MG25-18B	MG25-18G	M25×1.5	18-13	25	25.5	15	33	33
MG32-25B	MG32-25G	M32×1.5	25-18	32	33	15	41	41
MG40-30B	MG40-30G	M40×1.5	30-24	40	41	20	50	50
MG50-39B	MG50-39G	M50×1.5	39-30	50	51	22	62	61
MG63-49B	MG63-49G	M63×1.5	48.5-40	63	64	25	75	75
